Side Tilt Carriage - There are actually 4 sizes of hook type tine carriages rated by the blade carriage lifting capability. Hook type tine carriages have been consistent.
Class I carriages are rated for loads as much as 2000 lbs. The carriage bar spacing utilized for Class I is thirteen inches. Class II carriages are rated for loads as much as 5,550 lbs. Their carriage bar spacing is 16 inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this particular class is 20 inches. Class IV carriages are rated for loads up to 15,500 lbs. The carriage bar spacing for this capacity is 25 inches.
Pin mounted forks differ by the amount of offset between the fork and the tine eye. Various manufacturers would differ the carriages for pin type forks. Carriage capacity will be established by the carriage pin size and by the tine size.
Click to Download the pdf
